WG
WG2004.NET
4-Door Control Kit with Reader/Switch/Power Unit/Key Fob/180kg Magnetic Locks
EAN: 0520931664701
UPC: 520931664701
Antitheft
Note The item is located at Pico Rivera, California, 90660, United States and can be handled in 1 business day.
4-Door Access Control System with Enclosure/RFID Reader/Switch/Power Supply/
100 Key Fobs/180kg(300lbs) Force Magnetic Lock For Security System
4-Door Access Control
Download Software +Wiring diagram+Software Introduction link below:
Win7ï¼http://zl.hwpan.com/u40102105/Gregzhong/Mr.Lau/mjenWin7.rar
Win8ï¼http://zl.hwpan.com/u40102105/Gregzhong/Mr.Lau/mjenWin8.rar
Noteï¼Win8 PC should activate .Net Framework 3.5(Win8 default contains .Net Framework 4.5,but 3.5 is needed for the access software)
Double click "setup.exe".After installation,username:ABC,Password:123
Registering code is :2004
Registering name can be anything you like.
Tools>Extended functions>password:5678
RFID Readers
Parameters:
1) Dimension: 74mm*116mm*16mm
2) Card Type: 125khz EM4100/4102 card
3) Output Format: WG26/34
4) Reading Distance: 5-10cm
5) Working Frequency: 125khz
6) Read Speed: <0.2s
7) Voltage: 9-16v
8) Weatherproof/Dust Proof: Yes
9) Circuit protection: Yes
10) Internal antenna: Yes
Magnetic Lock:
Collinear Load Test 180kg,300pounds
The Standard Voltage is 12VDC when Finished
MOV Provides Reverse Current Protection
Suitable For Wooden Door, Glass Door, Metal Door, Fireproof Door
LED Indicates the Door Status
Anti-Residual Magnetism Designed
High Strength Material, Anodized Aluminum Housing
Package includes
1 pcs 4-door access control board with iron box power supply
4 pcs ID reader
4 pcs 180kg magnetic lock
4 pcs exit swithc
100 pcs ID tag
