Generic

14006478

US-020 Ultrasonic Module Distance Measuring Transducer Sensor

EAN: 0791090869638

UPC: 791090869638

Relay Control Module

US-020 ultrasonic module distance measuring sensor
Working voltage: DC 5 V
Induction Angle: Less than 15

This US-020 ultrasonic module can realize 2 ~ 700cm of non-contact ranging function, has 5 V of wide
voltage input range, static power consumption is less than 3mA. Their own temperature sensor will
revise the ranging and has many communication modes like GPIO, just like watchdog inside, very stable
and reliable.

Description:

US-020 ultrasonic module distance measuring sensor
Working voltage: DC 5 V
Static current: 3 mA
Working temperature: 0 ~ + 70°
Output way: GPIO
Induction Angle: Less than 15°
Detection range:2 cm to 700 cm
Detecting precision: 0.3 cm + 1%
UART mode serial configuration: Baud rate, starting a 9600 1, and stop bits one, who is black and white, eight data parity checking, no flow control.
Sensor size: Approx. 45 x 20 x 1.6mm
Hole diameter: Approx. 1mm

Package Included:

1 x US-020 ultrasonic module distance measuring sensor

Note: Please take note that we have 2 different kinds in stock and the colors are different. (Please refer to the pictures) We will send one kind at random. Please in kind prevail.
