SuntekStore Online

3 1/2 Digital Red LED 200mA DC Amp Current Panel Meter

EAN: 0721762923894

UPC: 721762923894

Voltmeter

A 3 1/2 LED DC voltage meter
High precision and stable
Polarity reversed protection
Bright red LED display
Housing with self-lock tips for panel mounting

Description:

A 3 1/2 LED DC current meter
High precision and stable
Polarity reversed protection
Low power consumption
Bright red LED display
Housing with self-lock tips for panel mounting

Specification:

Model: GDD5135A-DC200mA-P12V
Power Voltage: DC6-15.5V
Input Signal: 0 ~ DC 200mA
Measurement Range: 0 ~ DC 200mA
Display Range: 0 ~ ±199.9 mA
Display Solution: ±0.1mA
Zero: Automatic
Sampling Time: 2.5 seconds
Polarity Display: Automatic
Operating Temp: 0 ~ 50 deg C
Temp Coefficiency: less than 50PPM
Exterior Control: Configurable decimal points
Overrange Indication: 1 or -1 is displayed
Running Current: less than 50mA
0.56 inch red LED
Outline Size (L x W x H): Approx. 3.1 x 1.7 x 0.8 inch / 79 x 43 x 21mm
Screen Size (L x W): Approx. 2 x 0.9 inch / 51 x 24 mm
Housing Material: ABS
LED Color: Red
Housing Color: Black

Caution: Please be reminded that some of the parts are with high voltage; don't touch the parts of the panel

Package Includes:

1 x LED DC current meter
1 x Connecting cable
