PHILIPS 8000K Ultra Thin HID Xenon Conversion Kit H13

Headlight & Tail Light Conversion Kits

2 x Philips Ultra Slime Ballasts XLD145 German Made , 2 x Authentic Philips 8000K ULTINON Xenon Bulbs German Made
Color temperature: 8000K , Power consumption: 35watts , Voltage: 85V +/- 17V
Luminous flux: 2800 , Service Life: up to 3000hrs , Input Voltage: 9V-16V
Working current (Steady state): 3.5 A nom
Ignition voltage: 24kV Peak Max, 18kV Peak Min

The Ultinon family of automotive discharge lamps was introduced by Philips in 2001 to meet the significant aftermarket demand for head lighting units having a 8000K color temperature, higher than the standard 4100K type. The 4100K lamps can produce headlight beams of distinctly different colors depending on the design of the optical system into which they are incorporated. Many HID headlights now employ projection lens systems which capture all light from the lamp, thoroughly homogenize it, and then project a uniform color beam out through a mask and lens. Color variation from one projection system to another is minimal, the only difference sometimes occurring around the edge of the beam where chromatic aberrations from imperfect lenses may give the beam a purple colored lining. However with 4100K lamps in reflector style headlights, the beam will often be found to have a yellow or green color in the upper areas. The light here originates from the lower portion of the reflector. Light hitting that part of the reflector must pass through the lower half of the arc tube in which the pool of yellow-colored molten metal halide salts resides, and much of the blue light is therefore filtered out in this area.
